Growatt SPM 6000TL-HU 6kW Single-Phase Low-Voltage Hybrid Inverter

Growatt SPM 6000TL-HU — 6kW Single-Phase Low-Voltage Hybrid Inverter

The Growatt SPM 6000TL-HU combines solar generation, low-voltage battery storage, grid connection and generator input in one compact IP65 inverter. Designed for residential and small commercial energy storage, it delivers fast 10 ms backup switching and supports flexible system expansion.

KEY BENEFITS

• High PV input: up to 12 kW PV access power and 9 kW usable PV power.

• Dual MPPT: 2 independent trackers, 22 A maximum input current per MPPT.

• Low-voltage battery support: 40–60 V batteries with up to 140 A charge and discharge current.

• Reliable backup: 6 kW backup output with 10 ms UPS transfer time.

• Generator ready: up to 9.2 kW generator input.

• Flexible expansion: up to 6 units in parallel; supports 400 V three-phase systems.

• Quiet and durable: natural cooling, ≤30 dB(A), IP65 protection.

TECHNICAL SPECIFICATIONS

Rated AC output power: 6,000 W

Maximum PV access power: 12,000 W

Maximum usable PV power: 9,000 W

Maximum DC voltage: 600 V

MPPT voltage range: 150–550 V

Battery voltage range: 40–60 V

Maximum charge/discharge current: 140 A

Maximum efficiency: 98.1%

Dimensions (W × H × D): 330 × 580 × 232 mm

Weight: 26 kg

Protection rating: IP65

Communication: WiFi/LAN; RS485/CAN/USB

Warranty: 10 years

APPLICATIONS

Ideal for homes, villas and small commercial sites requiring solar self-consumption, battery storage, backup power and generator integration.

OFFICIAL DOCUMENTS

Datasheet: https://africa.growatt.com/upload/file/SPM_3000-6000TL-HU_Datasheet_EN_202601.pdf

Official product page: https://africa.growatt.com/products/spm-3000-6000tl-hu

Download official Growatt datasheet (PDF)
